Tus qauv
|
Vsr -910 Ub |
Vsr -210 Ub |
Vsr -610 Ub |
|
Vsr -510 Ub |
Vsr -100 Ub |
Vsr -100 Ub
Lub hauv paus rau phau ntawv
• Ib Leeg-Theem Cov Khoom Roj Siab Purulatorr
• 10μm. Ra nto tas (25μIN. RA yeem)
• Txo cov ntim sab hauv sab hauv kom luv luv lub sij hawm luv luv
• Txhua yam ntaub ntawv siv tau raws li ANTM A479 / A484 / A276 tus qauv twg
• Sab hauv cov txuas rau cov kev ntsuas siab
• Flow muaj peev xwm: Txog 30 SLPM (Txuj Ci), txog 120 SLPM (YOOJ YIM)
• Kev tswj hwm siab yog li
• Hlau-rau-hlau foob rau cov cua
• Qhov hluav taws xob yooj yim los ntawm lub log tes
• 100% helium-tok-sim
Kev tsis muaj
| Ntaus | ib theem zuj zus |
|
| Inlet Siab P1 | Max. 3500 PSIG | |
| Qhov hluav taws xob siab P2 | 10/30/60/100/150 PSIG | |
| Ua siab loj | 5000 PSIG | |
| Tawg ceev | 10000 PSIG | |
| Nto tas | 10μin. Ra (25μm. RA yeem) | |
| Lub Rooj Zaum Valve | Pctfe (vespel® xaiv tau) | |
| Diaphragm | Hastelloy® C276 | |
| Inlets thiab outlets | 1/4 "/ 3/8" VCR Fitting thiab Tube Weld | |
| Bonnet chaw nres nkoj | 1/8 "NPT (ntawm Vaj Huam Sib Luag Mount xaiv, Bonnet chaw nres nkoj tsis yog xov) | |
| Qhov ntsuas kub ntau | -40} o f to +160 o f ({{{} o {3}} o c) | |
| Leak tus nqi: (rau cov cua) | 1x10 ^ {-9 mbar i / s nws | |
| (ntawm lub rooj zaum) | 1x10 ^ {-8 mbar i / s nws | |
| Ntws Muaj Peev Xwm | Cv {=0. 09 (cv =0. 15 yeem) | |
| Muab cov nyhuv siab | {{0 {}}. 35 PSEL sawv hauv kev xa khoom siab ib | |
| 100 psig source pressure drop @Cv=0.09 | ||
| {{0 {0}}. 5psig nce nyob rau hauv tus me nyuam siab ib | ||
| 100 psig source pressure drop @Cv=0.15 | ||
| Qho hnyav | kwv yees li. 1.35kg |
Khoom Daim Duab
Vsr -210 Ub
Lub hauv paus rau phau ntawv
• Ib Leeg theem Kev Tswjhwm
• 10μm. Ra nto tas (25μIN. RA yeem)
• Txo cov ntim sab hauv sab hauv kom luv luv lub sij hawm luv luv
• Txhua yam ntaub ntawv siv tau raws li ANTM A479 / A484 / A276 tus qauv twg
• Sab hauv cov txuas rau cov kev ntsuas siab
• Lub zog kho mob muaj cov dav dav txaus
• Kev tswj hwm siab yog li
• Hlau-rau-hlau foob rau cov cua
• Qhov hluav taws xob yooj yim los ntawm lub log tes
• 100% helium-tok-sim
• khi-diaphragm tsim
Kev tsis muaj
| Ntaus | ib theem zuj zus |
|
| Inlet Siab P1 | Max. 3000 psig | |
| Qhov hluav taws xob siab P2 | 30/60/100/150/250 PSIG | |
| Ua siab loj | 2550 psig | |
| Tawg ceev | 8000 psig | |
| Nto tas | 10μin. Ra (25μm. RA yeem) | |
| Lub Rooj Zaum Valve | Pctfe (vespel® xaiv tau) | |
| Diaphragm | Hastelloy® C276 | |
| Inlets thiab outlets | 1/4 "/ 3/8" lossis 1/2 "VCR Fitting lossis Tube Weld | |
| Bonnet chaw nres nkoj | 1/8 "NPT (ntawm Vaj Huam Sib Luag Mount xaiv, Bonnet chaw nres nkoj tsis yog xov) | |
| Qhov ntsuas kub ntau | -40} o f to +160 o f ({{{} o {3}} o c) | |
| Leak tus nqi: (rau cov cua) | 1x10 ^ {-9 mbar i / s nws | |
| (ntawm lub rooj zaum) | 1x10 ^ {-8 mbar i / s nws | |
| Ntws Muaj Peev Xwm | CV {=0. 65, CV =1. 1 (hf kev xaiv) | |
| Muab cov nyhuv siab | 3.5 psig sawv hauv tus me nyuam siab ib | |
| 100 PSIG RESELFOIGHT DIS | ||
| 4.2 psig sawv hauv tus me nyuam siab ib | ||
| 100 PSIG RESOURCE LUB CWJ POM (FC Option) | ||
| Qho hnyav | Kwv yees.2. {0 kg |
Khoom Daim Duab
Vsr -510 Ub
Lub hauv paus rau phau ntawv
• Ib Leeg-Theem Cov Roj Regulator
• 10μm. Ra nto tas (25μIN. RA yeem)
• Txo cov ntim sab hauv sab hauv kom luv luv lub sij hawm luv luv
• Txhua yam ntaub ntawv siv tau raws li ANTM A479 / A484 / A276 tus qauv twg
• Sab hauv cov txuas rau cov kev ntsuas siab
• Flow muaj peev xwm: Txog 30 SLPM (Txuj Ci), txog 120 SLPM (YOOJ YIM)
• Kev tswj hwm siab yog li
• Hlau-rau-hlau foob rau cov cua
• Qhov hluav taws xob yooj yim los ntawm lub log tes
• 100% helium-tok-sim
• khi-diaphragm tsim
Kev tsis muaj
| Ntaus | ib theem zuj zus |
|
| Inlet Siab P1: | Max. 3500 PSIG | |
| Qhov hluav taws xob siab P2: | 10/30/60/100/150 PSIG | |
| Deg tas: | 10μin. Ra (25μm. RA yeem) | |
| Lub Rooj Zaum Valve: | Pctfe (vespel® xaiv tau) | |
| Diaphragm: | Hastelloy® C276 | |
| Inlets thiab outlets: | 1/4 "/ 3/8" VCR Fitting lossis Tube Weld | |
| Bonnet chaw nres nkoj: | 1/8 "NPT (ntawm Vaj Huam Sib Luag Mount xaiv, Bonnet chaw nres nkoj tsis yog xov) | |
| Kub Ntau: | -40} o f to +160 o f ({{{} o {3}} o c) | |
| Leak tus nqi: | (rau cov cua): 1x10 ^ -9 mbar i / s nws | |
| (Ntawm lub rooj zaum): | 1x10 ^ {-8 mbar i / s nws | |
| Txaus muaj peev xwm: | Cv {=0. 09 (cv =0. 15 yeem) | |
| Muab cov nyhuv siab: | {{0 {}}. 35 PSEL sawv hauv kev xa khoom siab ib | |
| 100 psig source pressure drop @Cv=0.09 | ||
| {{0 {0}}. 5psig nce nyob rau hauv tus me nyuam siab ib | ||
| 100 psig source pressure drop @Cv=0.15 |
Khoom Daim Duab
Vsr -610 Ub
Lub hauv paus rau phau ntawv
• Ib Leeg theem Kev Tswjhwm
• 10μm. Ra nto tas (25μIN. RA yeem)
• Txo cov ntim sab hauv sab hauv kom luv luv lub sij hawm luv luv
• Txhua yam ntaub ntawv siv tau raws li ANTM A479 / A484 / A276 tus qauv twg
• Sab hauv cov txuas rau cov kev ntsuas siab
• Kev tswj hwm siab yog li
• Hlau-rau-hlau foob rau cov cua
• Qhov hluav taws xob yooj yim los ntawm lub log tes
• 100% helium-tok-sim
Kev tsis muaj
| Ntaus | ib theem zuj zus |
|
| Inlet Siab P1 | Max. 3500 PSIG | |
| Qhov hluav taws xob siab P2 | 10/30/60/100 PSIG | |
| Nto tas | 10μin. Ra (25μm. RA yeem) | |
| Lub Rooj Zaum Valve | Pctfe (vespel® xaiv tau) | |
| Diaphragm | Hastelloy® C276 | |
| Inlets thiab outlets | 1/4 "/ 3/8" 1/2 VCR Fitting lossis Tube Weld | |
| Bonnet chaw nres nkoj | 1/8 "NPT (ntawm Vaj Huam Sib Luag Mount xaiv, Bonnet chaw nres nkoj tsis yog xov) | |
| Qhov ntsuas kub ntau | -40} o f to +160 o f ({{{} o {3}} o c) | |
| Leak tus nqi: (rau cov cua) | 1x10 ^ {-9 mbar i / s nws | |
| (ntawm lub rooj zaum) | 1x10 ^ {-8 mbar i / s nws | |
| Ntws Muaj Peev Xwm | Cv =0. 13 | |
| Muab cov nyhuv siab | {{0 {}}. 25 PSIG nce nyob rau hauv kev xa khoom siab ib | |
| 100 PSIG RESELFOIGHT DIS |
Khoom Daim Duab
Vsr -910 Ub
Lub hauv paus rau phau ntawv
• Ib Leeg theem Kev Tswjhwm
• 15μm. Ra max. 10μin Ra Max Yeem
• Tsim rau Cov Khoom Siv Hluav Taws Xob Tshwj Xeeb
• khi-diaphragm tsim nrog bellows hnov lub caij
• Txhua yam ntaub ntawv siv tau raws li ANTM A479 / A484 / A276 tus qauv twg
• Hlau-rau-hlau foob rau cov cua
• 100% helium-tok-sim
Kev tsis muaj
| Ntaus | ib theem zuj zus |
|
| Inlet Siab P1 | Max. 3500 PSIG | |
| Qhov hluav taws xob siab P2 | 30/60/100/150 PSIG | |
| Nto tas | 10μin. Ra (25μm. RA yeem) | |
| Lub Rooj Zaum Valve | Pctfe (vespel® xaiv tau) | |
| Diaphragm | Hastelloy® C276 | |
| Inlets thiab outlets | 1/2 "/ 3/4" lossis 1 "VCR Fitting lossis Tube Weld | |
| Bonnet chaw nres nkoj | 1/8 "NPT (ntawm Vaj Huam Sib Luag Mount xaiv, Bonnet chaw nres nkoj tsis yog xov) | |
| Qhov ntsuas kub ntau | -40} o f to +160 o f ({{{} o {3}} o c) | |
| Leak tus nqi: (rau cov cua) | 1x10 ^ {-9 mbar i / s nws | |
| (ntawm lub rooj zaum) | 1x10 ^ {-8 mbar i / s nws | |
| Ntws Muaj Peev Xwm | Cv {{{{{0}}}}}}} =4. 0 |
Khoom Daim Duab
Siab Purity RegulatorCov neeg siv phau ntawv qhia (hauv cov lus yooj yim)
Hauv ntej, nws yog qhov "siab purity roj borguard" uas ua rau koj cov pa siab tshaj plaws ntawm txoj cai kom tsis txhob cia ib qho khoom muaj nqis khiav tawm. Txawm hais tias koj nyob hauv chav tsev, cov chaw khomob, lossis cov kev tswj hwm cov neeg siv tshuaj, cov kev tswj hwm cov kev tswj hwm Tom qab tag nrho, nrog cov roj siab siab yog qhov tseem ceeb hauv ntau thaj teb, tswj xyuas qhov tseeb thiab kev nyab xeeb yog qhov tseem ceeb!
① Cov ntaub ntawv uas sawv ntsug
High-Purity Gases yog kus kus popy, thiab dog dig regulators xwb tsis tuaj yeem lis lawv. Lawv yuav xau lossis paug cov roj. Tias yog vim li cas peb siv cov khoom siv uas tuaj yeem ua tiav cov haujlwm: qib siab stainless hlau lossis cov ntawv ntim tshwj xeeb, thiab cov ntsaws ruaj ruaj ua los ntawm PTFE (Teflon) lossis cov ntaub ntawv zoo sib xws. Xav txog nws raws li cov regulator hnav kev ua tsis tau-tsis muaj cov pa tsis muaj sia, tsis muaj kev paug!
② Siab ntau uas haum koj cov kev xav tau
Peb cov regulators ua haujlwm thoob plaws ntawm cov kev ntsuas, los ntawm ultra-siab pressures (5, {2}} psi thiab dhau mus rau 1 psi lossis qis dua). Nws zoo li muaj lub cav turbocharged uas tuaj yeem hloov cov khoom plig kom yooj yim, yoog raws txhua qhov xwm txheej ntawm kev loj heev kom qeeb, ua haujlwm zoo.
③ Kev Nyab Xeeb Tseem Ceeb Onboard
Siab Tag Ntsoov: Yuav tsum saib xyuas lub siab kom koj thiaj paub.
Lub Valve Valve: Tso tawm qhov txiav txim siab yog tias nws mus dhau qhov kev tsis muaj kev nyab xeeb, khaws txhua yam hauv kev kos.
Kos Valve: Nres ib lub backflow, ua kom muaj roj tsis ua rau tsis muaj kev xav tsis thoob.
④ Ntws tswj uas yog chaw-rau
Hauv cov ntawv thov yuav tsum muaj siab huv, cov dej yuav tsum muaj tseeb, ib yam li tus kws kos duab txhuam hniav. Cov roj ntau dhau yog nkim, tsawg heev tuaj yeem pov cov txheej txheem sim lossis cov txheej txheem ntau lawm. Peb cov neeg tswj hwm ua kom qhov raug ntws mus rau hauv ± 1%, ua kom txhua yam mus raws nraim li tau npaj.
Cov lus nug uas nquag - Q & A
Tsis yog! Siv ib tus tswj hwm ib txwm yog zoo li sim siv cov sab cib kom muaj dej. Cov kev tswj hwm tsis tu ncua tuaj yeem paug cov roj, ua rau muaj dej siab, lossis txawm tias puas cov khoom puas. Ib lub hoobkas ib zaug siv cov roj tsis ncaj ncees rau cov roj siab siab thiab raug kev txom nyem ib qho kev nqhis dej loj, raug nqi rau lawv ib qho yuam kev!
Saib rau peb lub cim no:
- Lub siab ntsuas yog ua yeeb yaj kiab, zoo li nws muaj cov caffeine overdose.
- Frost yog tsim tsa ib puag ncig cov kev sib txuas (sijhawm rau kev kuaj).
- Ib qho txawv txawv qe tsw tsw (peb ntxiv cov lus ceeb toom thaum muaj cov kua). Yog tias koj pom cov no, muab kev hu rau peb!
Nws tsis yog foob pob hluav taws kev kawm, tsuas yog ua raws li "peb ua thiab peb qhov tsis ua":
UaTxheeb xyuas cov dej xau tsis tu ncua (siv peb cov tes kuaj tas).
UaNtxuav cov kev sib txuas thiab ua kom lawv hmoov av dawb.
Uasau ib qho siab hloov.
Tsis txhobNtswj lub valve zoo li koj tab tom qhib ib lub hub ntawm pickles.
Tsis txhobSim ua kom sib nrug sib nrug ntawm qhov chaw koj tus kheej (tawm mus rau tus Pros).
Tsis txhobCia nws tawm hauv lub hnub rau "Sunbathe."
Tsom rau peb tus lej tseem ceeb no:
- Inlet Siab(khij lub tog raj kheej daim ntawv rau qhov no).
- Ua Haujlwm Siab(Nug koj cov cuab yeej muab kev pab).
